CC- 1 CF Center Channel
CC – 1CF center channel is compact yet powerful. Designed to deliver high performance it boasts a 3/4" thick front baffle, polypropylene capacitors and air cored inductors.. Total height is just under 5.5”. Dual 4” woven carbon fibre mid-bass drivers in conjunction with a high performance textile tweeter, provide excellent full range performance wide dispersion and dialogue intelligibility.A rear mounted volume control provides precise high frequency level adjustment for virtually any room or electronics.. The front driver panel is angled 11 degrees for optimum placement either above or below TV screen.


System Design     Dual 4 “ WTW  Shielded Center Channel
Woofers 2 ea  4 “ carbon fibre shielded
Tweeter  1 ea  ¾” shielded Vifa textile dome
Crossover                             Minimum phase 2.2 khz
Frequency Resp   55 hz to 20 khz
Sensitivity      89 db
Power Min/ Max    10 W – 120 W
Impedance     6 Ohms
Dimensions   5.5 ” h x 17” w x 7/ 6 “ d – 11 deg angle
FinishesBlack gloss, Flat Black, Cherry (shown above)

      Shown in Dark Red Cherry
